BFT LUX GV-2B UL and CSA 120V Hydraulic Operator | BFT-P935014-00010

BFT LUX GV-2B UL and CSA 120V Hydraulic Operator (Stops Needed in the Open and Close Positions).

Manufacturer's Warranty Period

• 2 Years

Technical Specifications

• Control Panel: RIGEL 4 UL/CSA (suggested) or RIGEL5 with cap
• Reversible/Irreversible Operator: Irreversible
• Power Supply: 15.35” (390 mm)
• Absorbed Power: 0.33 hp (250 W)
• Thermal Protection: Integrated
• Rod Working Stroke: 11.02’’ (280 mm)
• Rod Speed: 0.55 ips (14 mm/s)
• Opening And Closing Time: 17 s
• Slowdown: On rod extension
• Impact Reaction: None
• Lock: Hydraulic opening/closing
• Manual Release: Release key
• Operating Cycle: Intensive use
• Environmental Conditions: From 14°F (-10°C) to 140°F (+60°C)
• Degree Of Protection: IP57
• Operator Weight: 19 lbs (~8,7 kg

Product Literature

• BFT P935014 00010 Instruction Manual (ESP)
• BFT P935014 00010 Spec Sheet
