BFT P7 120V UL and CSA Hydraulic Operator | BFT-P935060-00003

Reversible hydraulic operator for swing gates up to 23' and 1,100 lbs in weight. Cycle time 42+slowdown sec. Useful travel 15". max angle 123 °. Closing slowdown

Features

• The rear articulated brackets and jointed rod make installation simple and reliable in all situations.
• The brass release knob, protected with a personal key, facilitates the manual opening of the gate in the event of a power cut.
• The closing slowdown guarantees silent, smooth movements on even the biggest gates. Also, the adjustment screw makes it possible to adapt the slowdown intensity to the needs of each situation.

Manufacturer's Warranty Period

• 2 Years

Technical Specifications

• Control unit: RIGEL 6
• Board power supply: 230 V
• Motor voltage: 120 V
• Power consumption: 250 W
• Max. width of door/gate wing: 23 ft (7 m)
• Max. weight of door/gate wing: 1102 lbs (500 kg)
• Useful rod stroke: 15 inch (390 mm)
• Maximum angle: 123 °
• Cycle time: 42+slowdown sec
• Type of limit switch: Work time
• Slowdown: During closing
• Locking: Solenoid Lock
• Release: Reversible
• Impact reaction: Hydraulic clutch
• Frequency of use: Very intensive
• Protection rating: IP55
• Environmental conditions: 14 ÷ 140 °F (-10 ÷ 60 °C)
• Interconnectivity: No
