D&D Technologies Shut It BadAss Barrel Hinge | DND-CI3950

The BadAss Barrel Hinge is the strongest and most versatile gate hinge on the market. Ideal for nearly all heavy-duty gate installations the BadAss Barrel Hinge is the game changer in the industry. The gate hinge can be installed where a full 180-degree gate opening is required and has the ability to reduce the gap between the end post and gate to under 1⁄2” (13mm).

Features

• The strongest and most versatile hinge on the market
• Ideal for nearly all flat post installations
• Bolt-on and weld-on installations
• Swings 180º if required

Specifications

• Brand: Shut It® BadAss
• Product Code: CI3950
• Gate Application: Pedestrian Gate, Driveway Gate - Double, Driveway Gate - Single, Pet Gate, Playground Gate, Public/Commercial Gate, Automated/Electric Gate, Security Gate, Privacy Gate
• Gate Type: Non-Self-Closing
• Gate Material: Steel/Ornamental Iron
• Approx Gate Size: 2m H x 3m W - (7ft x 10ft)
• Gate Frame/Post Shape: Square-to-Square
• Min Post Size: 40mm+ (1½")
• Ideal Gate Gap: Fixed at 13mm (½"),
• Fixing Method: Bolt-On, Weld-On
• Color/Finish: Zinc
• Load rating per gate: 1,360kg (3,000 lbs)
• Maximum gate weight: 680kg (1,500 lbs)
• No. of Bearings: 4
• Yoke Material: Steel
• Body Material: Steel
• Height: 5.9
