FAAC 412 115V DX/SX Arm Only

The FAAC 412 115V DX/SX Arm Only is a genuine replacement operator arm for the FAAC 412 swing gate system. Designed for residential single-leaf swing gates, it delivers smooth, quiet, and reliable automation for gates up to 14 ft. wide and 500 lbs. Available in DX (right-hinged) or SX (left-hinged) configurations, this arm is ideal for replacing worn or damaged units while keeping your gate system running at peak performance.

Note: This is the arm only. Control panel, mounting hardware, and accessories are not included and must be purchased separately if required.

Features

• Genuine FAAC replacement – ensures compatibility and long-lasting durability.
• DX (right) or SX (left) arm options for proper gate alignment.
• Mechanical locking in open and closed positions (no external lock required in most cases).
• Manual release with key operation for emergencies or power outages.
• UL 325 compliant with anti-crush safety via control board.
• Designed for residential duty – smooth and quiet operation.
• Weather-resistant housing with built-in thermal protection.

Technical Specifications

• Power Supply: 115 VAC, single-phase
• Power Consumption: ~280 W
• Gate Capacity: Up to 14 ft. wide / 500 lbs.
• Opening Time (90°): ~16 seconds
• Rod Stroke: 11.4 in (290 mm)
• Cycles per Hour: Up to 18 (residential use)
• Operating Temp: −4°F to 131°F (−20°C to +55°C)
• Protection Rating: IP44 (weather-resistant)


Manufacturer's Warranty Period

• 3 years

Product Literature

• FAAC 412 Electromechanical Swing Gate Operator Manual
• FAAC 412 Electromechanical Swing Gate Operator Warranty Policy
