LiftMaster MATDCBB3 Mega Arm Tower Gate Operator

LiftMaster Mega Arm Tower Barrier Gate Operator (also known as LiftMaster MegaTower barrier gate opener) is a DC-powered addition to the LiftMaster gate opener family. Designed with a 24V DC (1/2 HP equivalent) motor, these models provide exceptional starting torque and continuous operation, making them ideal for most applications. Constructed with an aluminum alloy chassis, they're corrosion-resistant and light enough for one person to carry and install. The heavy-duty LiftMaster gate opener supports 6,000 cycles per day with an operator speed of 2.5 seconds to open or close.

The DC Solutions/Chamberlain Mega Arm was made to be unique in the industry through innovative design and solid engineering. It's a single State-of-the-Art universal electronics control board that eliminates the need for mechanical limit switches, relays, and contactors. Arm position is limited by a magnet mounted on the drive shaft, which is sensed by two magnetic sensors on the electronics controller. Its full-service controller is capable of accepting inputs from telephone entry, loop detectors, card readers, push buttons, barcode scanners, and is equipped with multiple vehicle memory buffers. Built-in regulated 24VDC backup power provided for accessories (detectors, receivers, card readers). The standard break-away arm design can allow the arm to be reused many times. Finally, its modern design and cutting-edge technology will make the MEGA ARM the perfect choice for all your parking control applications.

Please Note: Barrier arm is not included with the purchase of the operator. We offer different barrier arms in the option section to best suit your needs. If you have any questions, please call us at (800)-730-8382 to speak with one of our representatives, who will be happy to assist you in configuring your order.

Manufacturer's Warranty

Features

• Radio Receiver Built-in
• Aluminum Alloy Chassis
• Two 12V/7AMP Batteries (FASBAT)
• Max draw: .5 amps
• Soft Start/Stop
• DC Operator System
• Right or Left-Handed Operation
• Breakaway Arm
• Control Inputs
• Inherent Obstruction Sensing
• LED Indicators
• Max draw: .5 amps
• Dual Gate Operation
• Dynamic Braking
• Magnetic Sensors
• Timer to Close
