UNV 2MP WDR Lighthunter IR Network Dome Camera | UNV-IPC3232SB-AHDZK-I0

UNV 2MP WDR Lighthunter IR Network Dome Camera | UNV-IPC3232SB-AHDZK-I0

Features
  • High-quality image with 2MP,1/2.8’’ CMOS sensor.
  • 1920*1080@60fps in the mainstream, deliver detailed live while 60fps keeping it smooth and closer to the real image.
  • Ultra 265, H.265, H.264, MJPEG
  • 5X optical zoom allows for closer viewing of subjects.
  • Lighthunter product technology ensures ultra-high image quality in a low illumination environment.
  • Up to 120 dB Optical WDR (Wide Dynamic Range).
  • DC12V or PoE (IEEE 802.3af) power supply
  • Wide voltage range of ±25% in DC
  • Audio 1 in and 1 out, Alarm 2 in and 1 out 
Technical Specifications

Camera

  • Sensor: 1/2.8", 2.0 megapixel, progressive scan, CMOS
  • Minimum Illumination: Colour: 0.001 lux (F1.2, AGC ON) 0 lux with IR
  • Day/Night: IR-cut filter with auto switch (ICR)
  • Shutter: Auto/Manual, shutter time: 1 ~ 1/100000s
  • Adjustment angle: Pan: 0° to 355°, tilt: 0° to 70°, rotate 0° to 355°
  • WDR: 120dB
  • S/N: >52dB
  • Lens: [email protected], AF automatic focusing and motorized zoom lens
  • Iris: Fixed
  • Angle of View (H): 98.2°~30.6°
  • Angle of View (V): 53.3°~ 17.3°
  • Angle of View (O): 127.7°~37.6°
  • DORI Distance
    • Lens: 2.7
    • Detect (m): 70.9 (232.5ft)
    • Observe (m): 28.4 (93.0ft)
    • Recognize (m): 14.2 (46.5ft)
    • Identify (m): 7.1 (23.3ft)
  • IR Range: Up to 50m (164 ft) IR range
  • Wavelength: 850nm
  • IR On/Off Control: Auto/Manual

Video

  • Video Compression: Ultra 265, H.265, H.264, MJPEG
  • H.264 Code Profile: Baseline profile, Main profile, High profile
  • Frame Rate
    • Main Stream: 1080P (1920*1080),Max 60fps;
    • Sub Stream: 1080P (1920*1080), Max 60fps;
    • Third Stream: D1 (720*576), Max 60fps
  • Video Bit Rate: 128 Kbps~16 Mbps
  • ROI: Up to 8 areas
  • Video stream: Triple streams
  • OSD: Up to 8 OSDs
  • Privacy Mask: Up to 4 areas


  • White Balance: Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
  • Digital Noise Reduction: 2D/3D DNR
  • Smart IR: Support
  • Flip: Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
  • HLC: Supported
  • BLC: Supported
  • Defog: Digital Defog

Events

  • Basic Detection: Motion detection, Audio detection, Tampering alarm
  • General Function: Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Audio

  • Audio Compression: G.711, G.711A
  • Audio Bitrate: 64 Kbps
  • Two-way audio: Supported
  • Suppression: Supported
  • Sampling Rate: 8KHZ

Storage

  • Edge Storage: Micro SD, up to 256GB
  • Network Storage: ANR, NAS (NFS)

Network

  • Protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS
  • Compatible Integration: ONVIF (Profile S, Profile G, Profile T), API, SDK
  • User/Host: Up to 32 users. 2 user levels: administrator and common user
  • Security: Password protection, strong password, HTTPS encryption, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE, and digest authentication for ONVIF
  • Client: GuardStation/GuardLive/Guardview
  • Web Browser: Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below

Interface

  • Audio I/O: 1/1
  • Alarm I/O: 2/1
  • Serial Port: 1 RS485
  • Built-in Mic: Support
  • Video output: 1 BNC(For debugging)
  • Network: 1 * RJ45 10M/100M Base-TX Ethernet

Certifications

  • EMC
    • FCC CFR 47 Part 15
    • EN 55032:2015
    • EN 55024:2010
    • EN 61000-3-2:2014
    • EN 61000-3-3-2013
  • Safety
    • IEC 62368-1
    • EN 62368-1
    • UL 60950-1
  • Environment: CE-ROHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); REACH (Regulation (EC) No 1907/2006)

General

  • Power: DC12V (±25%), PoE (IEEE 802.3af)
  • Power consumption: Max 8.5W
  • Power Interface: 5.5mm coaxial power plug
  • Dimensions (Ø x H): Φ148.0 x 111.4mm (Φ5.8” x 4.4”)
  • Net Weight: 0.93kg (2.16lb)
  • Working Environment: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
  • Storage Environment: -40°C ~ 70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing)
  • Surge Protection: 6KV
  • Ingress Protection: IP67
  • Vandal Resistant: IK10
  • Reset Button: Support
Product Literature
$599.00
UNV 2MP WDR Lighthunter IR Network Dome Camera | UNV-IPC3232SB-AHDZK-I0—
$599.00
