Viking I770 Underground Swing Gate Operator Only (Stainless Steel) | VIK-VA-I770S
Viking I770 Underground Swing Gate Operator Only (Stainless Steel) | VIK-VA-I770S
The I-770 Underground Swing Gate Operator offers the solution to home and property owners who want to center all their attention on their gate. Nearly invisible, the I-770 is ETL Listed, UL325, and UL991 compliant.
The direct-drive DC gearhead unit is IP67 water-resistant and has a convenient manual release mechanism. The I-770S comes with a stainless steel chassis and a battery backup capable of 250 continuous cycles.
The I-770 is powered by the V-Flex control board, including speed control and diagnostic LCD display. This intuitive operator is solar efficient and ready to be powered with low voltage wiring, allowing versatility of installations.
VA-I770S Underground Swing Gate Operator Contains:
- 1 FA-10675315 I770 Drive Unit
- 1 FA-490110 I770 SS Foundation Box
- 1 FA-722121 I770 Open Positive Stop
- 1 FA-722122 I770 Close Positive Stop
Features
- Adaptive motor control
- Built-in thermostat-controlled heater
- Built-in voltmeter
- Lightning strike protection
- Multiple power options
- On-board display
- True battery back-up
- UL325 compliant
- Two monitoring inputs w/ up to 4 devices per input
- Adjustable speed control
- Anti-tailgating feature
- Fail secure mode
- Large box option
- Manual release - mechanical
- Multiple power outage options
- Positive stop limits
Manufacturer's Warranty Period
- 3 Years
Technical Specifications
- Maximum Gate Capacity: 12 ft at 650 lb
- UL 325 Classification: Class I, II, III, IV
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Voltage Current Specs: 120VAC - 1.5A or 240VAC - 1.0A (each motor)
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Alternative Power Source: 24VAC / VDC (60VA) or Solar
- Accessory Power: 24VDC - 750mA
- Power Consumption - Sleep: 28mA
- Motor Current (Typical): 3.0A
- Operating Temperature: -20°F (-28°C) to 131°F (55°C)
- Opening Angle: 110°
- Gate Speed: 13-15 sec./90°
- Battery Backup: 400 Continuous Cycles
Product Literature
Original: $1,588.99
-70%$1,588.99
$476.70Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Viking I770 Underground Swing Gate Operator Only (Stainless Steel) | VIK-VA-I770S
The I-770 Underground Swing Gate Operator offers the solution to home and property owners who want to center all their attention on their gate. Nearly invisible, the I-770 is ETL Listed, UL325, and UL991 compliant.
The direct-drive DC gearhead unit is IP67 water-resistant and has a convenient manual release mechanism. The I-770S comes with a stainless steel chassis and a battery backup capable of 250 continuous cycles.
The I-770 is powered by the V-Flex control board, including speed control and diagnostic LCD display. This intuitive operator is solar efficient and ready to be powered with low voltage wiring, allowing versatility of installations.
VA-I770S Underground Swing Gate Operator Contains:
- 1 FA-10675315 I770 Drive Unit
- 1 FA-490110 I770 SS Foundation Box
- 1 FA-722121 I770 Open Positive Stop
- 1 FA-722122 I770 Close Positive Stop
Features
- Adaptive motor control
- Built-in thermostat-controlled heater
- Built-in voltmeter
- Lightning strike protection
- Multiple power options
- On-board display
- True battery back-up
- UL325 compliant
- Two monitoring inputs w/ up to 4 devices per input
- Adjustable speed control
- Anti-tailgating feature
- Fail secure mode
- Large box option
- Manual release - mechanical
- Multiple power outage options
- Positive stop limits
Manufacturer's Warranty Period
- 3 Years
Technical Specifications
- Maximum Gate Capacity: 12 ft at 650 lb
- UL 325 Classification: Class I, II, III, IV
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Voltage Current Specs: 120VAC - 1.5A or 240VAC - 1.0A (each motor)
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Alternative Power Source: 24VAC / VDC (60VA) or Solar
- Accessory Power: 24VDC - 750mA
- Power Consumption - Sleep: 28mA
- Motor Current (Typical): 3.0A
- Operating Temperature: -20°F (-28°C) to 131°F (55°C)
- Opening Angle: 110°
- Gate Speed: 13-15 sec./90°
- Battery Backup: 400 Continuous Cycles
