Viking X390 Swing Gate Operator - Operator Only | VIK-VA-X390

The X-390 Swing Gate Operator features adjustable timer for automatic closure, high efficiency power supply.

This operator can be mounted directly to a column, making it a very popular option for homeowners who do not have the space for a pad-mounted gate opener. The X-390 has UL 325 and 991 safety listings.

Features

• Adaptive motor control
• Built-in thermostat-controlled heater
• Built-in voltmeter
• Lightning strike protection
• Multiple power options
• On-board display
• True battery back-up
• UL325 compliant
• Two monitoring inputs with up to 4 devices per input
• Adjustable speed control
• Anti-tailgating feature
• Fail secure mode
• Large box option
• Manual release - mechanical
• Multiple power outage options
• Two 4Ah batteries included
• Positive stops included

Technical Specifications

• Maximum Gate Capacity: 14 ft at 600 lb
• UL 325 Classification: Class I, II, III, IV
• Duty Cycle: 100%
• Operating Voltage: 24VDC
• Voltage Current Specs: 120VAC - 1.5A or 240VAC - 1.0A (each motor)
• Main Power Frequency: 50Hz / 60Hz
• Main Power Fuse: 4A Timed
• Alternative Power Source: 24VAC / VDC (60VA) or Solar
• Accessory Power: 24VDC - 750mA
• Power Consumption: - Sleep 28mA
• Motor Current (Typical): 2.0A
• Operating Temperature: -20°F (-28°C) to 131°F (55°C)
• Opening Angle: 120°
• Gate Speed: 10-13 sec./90°
• Battery Backup: 400 Continuous Cycles

Manufacturer's Warranty Period

• 3 Years
